MW-RFOG(H)XXXX/DW series RFoG ONU, adopts Passive Optical distribution Network(PON) to Realize bi-directional, interactive RF business. In FTTH network, It serves to transmission layer of RF video, DAVIC, DOCSIS, extending the optical network to home or building without the need of adjacent HFC optical node. Saving lots of RF amplifier, thus, it can improve the quality and stability of network operation. MW-RFOG(H)XXXX/DW uplink channels adopts burst mode, which can largely reduce the Funneling noise at uplink channels and improve stability of network operation. MW-RFOG(H)XXXX/DW uplink adopts 1610nm wavelength, Compatible with any FTTH PON technique, realize Triple-play. Built-in CWDM is optional, through 1310nm/1490nm and 1610nm(or 1590nm).
1. Uplink channels adopts burst mode,
2. Take use of RF and DOCSIS technique configuration optical distribution Network.
3. Using single-fiber with bi-direction mode that could reduce the fiber Consumption
4. No need of HFC optical node, reduce the cost of network maintenance and Operation.
5. Compatible with any FTTH PON technique, realize Triple-play.
6. Built-in CWDM is optional, through 1310nm/1490nm and 1610nm(or 1590nm).
7. Support the universal HFC STB,CM and Head-end equipment.
8. Transparent return path channel(no limitation on protocol and modulation mode).
9. Optical AGC function(reach the proper RF level) reduce the funneling noise.
10. Local feeding or remote feeding can be done through 75 coaxial cable.
11. Aluminum die-casting housing, favorable for heat dispersion.
